Baylan - Baylan BW Woltmann Type Cold Water Meter
Baylan BW Woltmann Type Cold Water Meter - BW
| Product | Baylan BW Woltmann Type Cold Water Meter |
|---|---|
| Brand | Baylan |
| Product Price | 0 LKR |
| Datasheet | Download |
Description
Product Overview
The Baylan BW Woltmann Type Cold Water Meter is a high-capacity industrial water meter designed for bulk water measurement in water distribution networks, commercial facilities, irrigation systems and industrial plants. With a durable cast-iron body, IP68-protected dry dial, very low pressure loss and excellent sensitivity at low flows, the BW series provides long-term accuracy and reliability even under demanding field conditions.
Key Features
- MID Certified
- IP68 protected dry-type measuring mechanism
- Suitable for all installation positions (horizontal, vertical, inclined)
- Woltmann design for industrial and high-flow applications
- Low pressure loss with high sensitivity at initial flow
- Internally & externally epoxy-powder painted body
- Optional AMR/optical reading capability
- Cast iron GG25 body with high corrosion resistance
- Designed for water supply and distribution networks
- Water temperature resistance up to 50°C
- Flanges comply with BS 4504 / DIN 2532 PN16
- All internal parts suitable for potable (drinking) water
- Service and spare parts available for 10 years
- 3-year manufacturer warranty
Technical Specifications
Brand: Baylan
Model: BW Series
Type: Woltmann Type – Cold Water Meter
Maximum Water Temperature: 50°C
Maximum Pressure: 16 bar
Environmental Class: Climatic –10°C to +55°C / Mechanical M1/O / Electromagnetic E2
Performance Data (Flow Range)
|
Meter Size (DN) |
Model |
Q3/Q1 |
Q4 – Overload Flow |
Q3 – Nominal Flow |
Q2 – Transitional |
Q1 – Minimum Flow |
Smallest Reading |
Max. Registration |
|
50 mm |
BW-50 |
≤160 |
31.25 m³/h |
25 m³/h |
0.25 m³/h |
0.156 m³/h |
0.001 m³ |
999999 |
|
65 mm |
BW-65 |
≤160 |
50 m³/h |
40 m³/h |
0.40 m³/h |
0.25 m³/h |
0.001 m³ |
999999 |
|
80 mm |
BW-80 |
≤160 |
78.75 m³/h |
63 m³/h |
0.63 m³/h |
0.393 m³/h |
0.001 m³ |
999999 |
|
100 mm |
BW-100 |
≤160 |
125 m³/h |
100 m³/h |
1.00 m³/h |
0.625 m³/h |
0.001 m³ |
999999 |
|
125 mm |
BW-125 |
≤160 |
200 m³/h |
160 m³/h |
1.60 m³/h |
1.00 m³/h |
0.001 m³ |
999999 |
|
150 mm |
BW-150 |
≤160 |
312.5 m³/h |
250 m³/h |
2.50 m³/h |
1.562 m³/h |
0.01 m³ |
9999999 |
|
200 mm |
BW-200 |
≤160 |
500 m³/h |
400 m³/h |
4.00 m³/h |
2.50 m³/h |
0.01 m³ |
9999999 |
|
BW |
Dimensions & Weights
|
DN |
Model |
Length (L) |
Width (B) |
Height (H) |
Flange Dia (D2) |
Hole Center (D1) |
Bolt Pattern |
Unit Weight (kg) |
Package Weight (kg) |
|
50 |
BW-50 |
200 mm |
165 mm |
190.2 mm |
165 mm |
125 mm |
4 × M16 |
7.80 |
12.32 |
|
65 |
BW-65 |
200 mm |
185 mm |
200 mm |
185 mm |
145 mm |
4 × M16 |
9.12 |
14.35 |
|
80 |
BW-80 |
225 mm |
199.5 mm |
234 mm |
200 mm |
160 mm |
8 × M16 |
13.46 |
19.55 |
|
100 |
BW-100 |
250 mm |
220 mm |
244 mm |
220 mm |
180 mm |
8 × M16 |
14.23 |
21.60 |
|
125 |
BW-125 |
275 mm |
250 mm |
286 mm |
250 mm |
210 mm |
8 × M16 |
20.10 |
32.00 |
|
150 |
BW-150 |
300 mm |
285 mm |
304 mm |
285 mm |
240 mm |
8 × M20 |
30.00 |
42.50 |
|
200 |
BW-200 |
350 mm |
340 mm |
375 mm |
340 mm |
295 mm |
12 × M20 |
35.20 |
53.20 |
|
BW |
Applications
- Water distribution networks
- Industrial water supply and pipelines
- Commercial buildings
- Irrigation systems
- Bulk water metering for utilities
Why Buy from FieldInstruments.lk?
- 100% genuine Baylan water meters
- Fast delivery across Sri Lanka
- Expert support for sizing & installation
- 10-year availability of genuine spare parts
- Trusted supplier for water utility, industrial & commercial metering
