Brother - Brother PT-E850TKW Industrial Tube, Ferrule & Label Printing Machine
Brother PT-E850TKW Industrial Tube, Ferrule & Label Printing Machine - PT-E850TKW
| Product | Brother PT-E850TKW Industrial Tube, Ferrule & Label Printing Machine |
|---|---|
| Brand | Brother |
| Product Price | 0 LKR |
| Datasheet | Not Available |
Description
The Brother PT-E850TKW Industrial Tube and Label Printer is designed to streamline cable, wire, ferrule, electrical-panel, and equipment identification tasks. Its twin-engine mechanism allows both tubes and labels to remain installed, eliminating the need to repeatedly remove and reload media when switching between applications.
The PT-E850TKW prints on TZe laminated labels from 3.5 mm to 36 mm wide and supports PVC tubes with diameters from 2.5 mm to 6.5 mm. Label printing speeds reach 60 mm/sec, while tube printing reaches 40 mm/sec, with a maximum print resolution of 360 dpi.
For professional workflow integration, the printer supports USB and wireless LAN connectivity. Brother's P-touch Editor software can be used for label design, database-driven printing, barcodes, graphics, logos, and other identification requirements. Wireless mobile printing is also supported through Brother's Pro Label Tool app.
Main Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Brother |
| Model | PT-E850TKW |
| Product Type | Industrial Tube / Ferrule & Label Printer |
| Printing System | Twin-Engine Tube and Label Printing |
| Keyboard | QWERTY |
| Label Media | TZe Laminated Tape |
| Heat-Shrink Media | HSe Heat-Shrink Tube |
| TZe Tape Widths | 3.5 / 6 / 9 / 12 / 18 / 24 / 36 mm |
| Maximum Tape Width | 36 mm |
| PVC Tube Diameter | Ø2.5 to Ø6.5 mm |
| Label Printing Speed | Up to 60 mm/sec |
| Tube Printing Speed | Up to 40 mm/sec |
| Print Resolution | 360 dpi |
| Printable Lines – Tube | Up to 2 Lines |
| Printable Lines – Label | Up to 17 Lines |
| Characters | 826 |
| Symbols | 465 |
| Barcode Support | 21 Barcode Protocols via P-touch Editor 5.1 |
| Cutter | Automatic Full Cut & Half Cut |
| Mirror Printing | Yes |
| File Storage | 99 Files |
| Memory Buffer | Up to 40,000 Characters |
| USB Interface | USB 2.0 Full Speed Type-B |
| Wireless LAN | IEEE 802.11b/g/n |
| Wireless Direct | IEEE 802.11n |
| WPS | WPS 2.0 |
| AC Adapter | AD9100ESA, 24 V |
| Optional Battery | PA-BT-4000LI Li-ion, 14.4 V |
| Dimensions (W × D × H) | 338 × 188 × 173 mm |
| Weight | 4.6 kg |
