Product Overview

The ifm PT5404 is a compact electronic pressure transmitter designed for reliable measurement of relative pressure in liquids or gases. It converts system pressure into a standard 4–20 mA analogue signal, making it ideal for process control, monitoring, and automation systems in industrial or fluid-handling applications. Its robust stainless-steel housing, wide operating range, and simple M12 connector make it a versatile choice for hydraulic, pneumatic, or general industrial use.

Key Features

• Measures relative pressure for liquids and gases with a measuring range of 0 … 10 bar.

• Provides analogue 4–20 mA output, compatible with PLCs, controllers, and data-logging systems.

• Compact stainless-steel housing with G¼ external thread — suitable for standard industrial pressure ports.

• Wide operating voltage range: 8.5 … 36 V DC — flexible for various power supply setups.

• High durability and robustness — suitable for harsh industrial environments, with vibration and shock resistance.

• Wide temperature range for medium and ambient temperatures (e.g. –40 °C to +90 °C) — usable in diverse conditions.

• Vacuum resistance down to –1 bar (i.e. absolute vacuum resistance) — allows measurement in suction or negative-pressure systems.

• Compact size and M12 connector for easy wiring and quick installation.

Technical Specifications

Brand: ifm electronic
Model: PT5404
Type: Electronic Pressure Transmitter (relative pressure)

Measuring Range: 0 … 10 bar (approx. 0 … 145 psi, 0 … 1 MPa)
Process Connection: G ¼ external threaded connection (standard industrial thread)
Output Signal: Analogue 4–20 mA current output
Supply Voltage: 8.5 … 36 V DC
Media: Liquids and gases compatible with stainless-steel wetted materials
Medium / Ambient Temperature Range: –40 °C … +90 °C
Vacuum Resistance: Up to –1 bar (i.e. can measure down to vacuum)
Protection / Housing: Stainless-steel body; designed for industrial environments
Electrical Connection: Standard M12 connector for easy wiring

Applications & Use Cases

• Monitoring pressure in hydraulic or pneumatic systems.

• Process control in industrial plants — pressure feedback for pumps, compressors, vessels.

• Integration into automation and control systems (PLCs / SCADA) for continuous pressure measurement.

• Fluid-handling, water/waste-water systems or chemical processing plants.

• Systems requiring compact, robust sensors for harsh or varying environmental conditions.

• Replacement of mechanical pressure gauges with electronic, output-ready sensors for digital monitoring.

Why Buy from FieldInstruments.lk

• We supply 100% genuine ifm electronic pressure transmitters — ensuring original factory-standard quality and full reliability.

• Fast and reliable delivery across Sri Lanka — get the sensor directly to your facility or project site.

• Competitive pricing and transparent sourcing — ideal for both single-unit purchases and bulk orders.

• Local technical support and after-sales service — we assist with selection, installation guidance, and configuration advice.

• Trusted supplier for industrial instrumentation — serving clients in automation, fluid handling, hydraulics, process control, and manufacturing sectors.
