TESTO - testo 760-2 - Digital multimeter
testo 760-2 - Digital multimeter - 760-2
| Product | testo 760-2 - Digital multimeter |
|---|---|
| Brand | TESTO |
| Product Price | 0 LKR |
| Datasheet | Download |
Description
Product Overview
The testo 760-2 Digital Multimeter is a True RMS multimeter designed for demanding electrical measurement tasks in industrial and commercial environments. Positioned above the 760-1 model, it offers an extended measurement range and additional functions, making it ideal for professional electricians and maintenance engineers.
Instead of a traditional rotary switch, the testo 760-2 uses intelligent function keys that automatically detect the measurement parameter based on socket assignment—reducing operating errors and improving safety. With a large backlit display, rugged IP64 housing, and enhanced performance capabilities, it delivers reliable results even in complex applications.
Key Features
• True RMS (TRMS) Measurement – Accurate readings on non-linear loads
• Automatic Measurement Parameter Detection
• Function Keys Instead of Rotary Dial
• Large Backlit Display (6,000 counts)
• Extended Voltage Range up to 1000 V
• Low-Pass Filter for Motor & Drive Testing
• Temperature Measurement Function
• IP64 Protection Class – Dust and splash resistant
• Robust Industrial Design
Technical Specifications
Manufacturer: Testo
Model: 760-2
Type: True RMS Digital Multimeter
Measurement Functions
Voltage (AC/DC)
• Range: 0.1 mV to 1000 V
Current (AC/DC)
• Range: 1 mA to 10 A
Resistance
• Range: 0.1 Ω to 60 MΩ
Frequency
• Range: 0.001 Hz to 512 kHz
Capacitance
• Range: 0.01 nF to 30,000 µF
Temperature (Type K Thermocouple)
• Range: –20 °C to +500 °C
Additional Functions
• Continuity test
• Diode test
• Low-pass filter
• Min/Max display
Accuracy & Display
• Basic accuracy: 0.5 %
• Display resolution: 6,000 counts
Safety & Protection
• Measurement category: CAT IV 600 V / CAT III 1000 V
• Protection class: IP64
• Standards: EN 61326-1, EN 61010-1, EN 61010-2-033
• Approvals: CSA, CE
Operating Conditions
• Operating temperature: –10 to +50 °C
• Storage temperature: –15 to +60 °C
• Dimensions: 167 × 85 × 45 mm
• Weight: 340 g
Scope of Supply
• testo 760-2 Digital Multimeter
• Batteries
• 1 set of measuring cables
• Temperature probe (Type K)
• Order No.: 0590 7602
Applications
• Industrial electrical maintenance
• Motor drives and variable frequency drives (VFDs)
• Troubleshooting non-linear loads
• HVAC electrical diagnostics
• Advanced installation testing
