Product Overview
The Fluke 700G06 Precision Pressure Test Gauge is a high-accuracy digital pressure gauge designed for calibration, testing, and industrial pressure measurement applications. With a measurement range of –12 to +100 psi (–0.83 to +6.9 bar), it is ideal for pneumatic systems, hydraulic systems, process industries, and calibration laboratories.

This gauge provides excellent accuracy up to ±0.05% of full scale and features a high-resolution digital display with bar graph indication. Its rugged industrial design ensures reliable performance in field and laboratory environments, and it can be used with Fluke pressure test pump kits for complete calibration solutions.

Key Features

• Pressure measurement range –12 to +100 psi (–0.83 to +6.9 bar)
• High accuracy ±0.05% of full scale
• Suitable for pressure and vacuum measurement
• High-resolution digital display with bar graph
• Rugged industrial design with protective holster
• Data logging capability (with 700G/TRACK software)
• Compatible with pneumatic and hydraulic test pumps
• Long battery life up to 2000 hours
• Compact and portable design
• Calibration certificate included

Technical Specifications

Manufacturer: Fluke
Model: 700G06
Type: Precision Pressure Test Gauge

Pressure Measurement

• Measuring range:
–12 to +100 psi
–0.83 to +6.9 bar

• Accuracy:
Positive pressure: ±0.05% of full scale
Vacuum: ±0.1% of full scale

• Resolution:
0.01 psi
0.0001 bar

• Burst pressure:
400 psi
26 bar

General Specifications

• Display: Digital display with bar graph and backlight
• Pressure connection: ¼ inch NPT male
• Battery type: 3 × AA alkaline batteries
• Battery life:
1500 hours continuous use
2000 hours typical use

• Dimensions: 127 × 114 × 37 mm
• Weight: 0.56 kg
• Housing: Rugged industrial housing with protective holster

Applications

• Pressure calibration
• Hydraulic and pneumatic system testing
• Industrial maintenance
• Process control calibration
• HVAC system testing
• Calibration laboratories
• Leak testing
• Instrument calibration
