NEXENS - NEXENS NWS9000 Automatic Weather Monitoring Station
NEXENS NWS9000 Automatic Weather Monitoring Station - NWS9000
| Product | NEXENS NWS9000 Automatic Weather Monitoring Station |
|---|---|
| Brand | NEXENS |
| Product Price | 0 LKR |
| Datasheet | Not Available |
Description
The NWS9000 is a compact automatic meteorological and ambient air monitoring station that integrates multiple environmental sensors into a single outdoor unit. Its modular configuration allows measurement parameters to be selected according to the application and specified through order codes A–G.
The station features RS485, RS232 and SDI-12 digital communication and supports Modbus, NMEA-0183 and ASCII communication protocols. A wide 7–30 VDC power supply range and only 1.7 W typical power consumption make it suitable for remote monitoring installations. When the internal heater is required, a minimum supply of 12 VDC is specified.
The NWS9000 uses a solid-state, maintenance-free design with no moving parts and an IP65-rated ABS/ASA housing, making it suitable for continuous outdoor operation. An integrated heater is available for operation in severe cold climates. Optional GPS, BeiDou and electronic compass modules can also be selected.
The compact design measures approximately Ø84 mm × 120–298 mm and weighs only 0.38 kg, making the NWS9000 suitable for installations where space, weight and power consumption are important considerations.
Key Features
- Compact all-in-one automatic weather station
- Urban ambient air monitoring capability
- Measures multiple meteorological parameters
- No moving parts
- Maintenance-free solid-state design
- 1.7 W low power consumption
- IP65 outdoor protection
- Built-in automatic heater for cold climates
- RS485 / RS232 / SDI-12 digital output
- Supports Modbus, ASCII and NMEA-0183
- Baud rate: 4800–19,200 bps
- Optional GPS / BeiDou positioning
- Optional electronic compass
- Optional PM1.0 / PM2.5 / PM10 measurement
- Optional solar radiation, illuminance and UV measurement
- Optional rainfall and altitude measurement
- Fully configurable measurement parameters through A–G order codes
- Pole/mast mounting
- Single-cable installation
- Compact and lightweight design
Technical Specifications
| Parameter | Specification |
|---|---|
| Product | NWS9000 Micro Automatic Meteorological Station |
| Product Type | Automatic Weather / Environmental Monitoring Station |
| Application | Weather, air quality, smart city, agriculture, industrial and research monitoring |
| Wind Speed Range | 0–40 m/s |
| Wind Speed Accuracy | ±5% |
| Wind Speed Resolution | 0.1 m/s |
| Wind Direction Range | 0–359° |
| Wind Direction Accuracy | ±3° |
| Wind Direction Resolution | 1° |
| Atmospheric Temperature | -40 to +80°C |
| Temperature Accuracy | ±0.5°C |
| Temperature Resolution | 0.1°C |
| Relative Humidity | 0–100% RH |
| Humidity Accuracy | ±5% |
| Humidity Resolution | 1% |
| Atmospheric Pressure | 150–1100 hPa |
| Pressure Accuracy | ±1 hPa |
| Pressure Resolution | 0.1 hPa |
| Rainfall Range | 0–200 mm/hr |
| Rainfall Accuracy | ±5% |
| Rainfall Resolution | 0.01 mm |
| Altitude Range | -500 to 9000 m |
| Altitude Accuracy | ±5% |
| Altitude Resolution | 1 m |
| Solar Radiation Range | 0–2000 W/m² |
| Solar Radiation Accuracy | ±5% |
| Solar Radiation Resolution | 0.1 W/m² |
| Illuminance Range | 0–200,000 lux |
| Illuminance Accuracy | ±5% |
| Illuminance Resolution | 0.1 lux |
| UV Radiation Range | 0–2000 W/m² |
| UV Radiation Accuracy | ±5% |
| UV Radiation Resolution | 0.1 W/m² |
| PM1.0 / PM2.5 / PM10 | 0–500 µg/m³ |
| PM Accuracy | ±10% |
| PM Resolution | 1 µg/m³ |
| Digital Output | RS232 / RS485 / SDI-12 |
| Communication Protocols | Modbus / NMEA-0183 / ASCII |
| Baud Rate | 4800–19,200 bps |
| Power Supply | 7–30 VDC |
| Heater Supply Requirement | ≥12 VDC |
| Power Consumption | 1.7 W |
| Internal Heater | Built-in, automatic cold-climate operation |
| Housing Material | ABS / ASA engineering plastic |
| Standard Colour | White |
| Optional Colour | Black |
| Protection Rating | IP65 |
| Operating Principle | Solid-state, maintenance-free |
| Mounting | Pole / mast, single cable |
| Dimensions | Ø84 mm × 120–298 mm |
| Weight | 0.38 kg |
Optional parameters are selected according to the order configuration. The measurement specifications above are taken directly from the supplied NWS9000 datasheet.
Configuration / Order Codes
The NWS9000 can be configured according to the required measurement parameters.
| Code | Configuration |
| A | Wind speed + wind direction + temperature + humidity + atmospheric pressure |
| B | Code A + rainfall |
| C | Code B + altitude |
| D | Code C + solar radiation |
| E | Code D + illuminance |
| F | Code E + UV radiation |
| G | Code F + PM2.5 + PM10 |
The datasheet specifies that parameters can also be selected and combined according to the user's requirements, with the required parameters and quantity to be specified when ordering.
Applications
The NWS9000 is suitable for:
- Smart-city environmental monitoring
- Urban weather monitoring
- Ambient temperature and humidity monitoring
- Wind monitoring
- Rainfall monitoring
- Urban air-quality monitoring
- PM2.5 and PM10 monitoring
- Roadside environmental monitoring
- Construction-area environmental monitoring
- Industrial environmental monitoring
- Solar PV site monitoring
- Solar-farm environmental monitoring
- Solar-resource monitoring
- Agricultural weather stations
- Crop environmental monitoring
- Irrigation planning support
- Greenhouse environmental monitoring
- Precision-agriculture systems
- Environmental research
- Meteorological research
- Air-quality studies
- University and laboratory projects
- Long-term outdoor environmental data logging
Installation & Integration
The NWS9000 is designed for pole or mast mounting using a single cable. Its Ø84 mm body is compatible with most universal sensor clamps. The IP65 enclosure is intended for outdoor all-weather operation.
For wind measurements, the datasheet recommends mounting the station 2–10 m above ground and avoiding nearby obstacles in the prevailing wind sector. For radiation and particulate sensors, an unobstructed sky view is recommended.
Communication & Integration
- RS485
- RS232
- SDI-12
- Modbus RTU
- ASCII
- NMEA-0183
- 4800–19,200 bps
- Power and communication through a single cable
What's Included
The supplied datasheet describes the NWS9000 as a configurable product, with measurement parameters selected through order codes A–G. Therefore, the exact sensor configuration and supplied accessories depend on the selected configuration at the time of purchase.
Ordering Information
Model: NWS9000
Configuration: Order Codes A–G
Lead Time: Stock items: 5–7 business days
Warranty: 12 months limited manufacturer warranty
MOQ: 1 unit; volume pricing available above 10 units
