Product Overview

The PFMB7202-N06-FN is a high-precision digital flow switch designed for monitoring and controlling the flow of air or nitrogen in pneumatic systems. With a clear two-colour display, flexible outputs and compact design, it offers both real-time monitoring and control functions in a single device — ideal for automation, energy-saving, and system diagnostics.

Key Features

• Two-colour digital display that improves visibility of flow conditions and alarm states.
• Wide flow rate measurement range (for the “7202” series) enabling use in larger systems.
• Integrated flow adjustment valve for easier commissioning and fine-tuning.
• Dual switch outputs plus analogue output (depending on variant) for flexibility in control and signalling.
• Compact, lightweight body (approx. 155 g) simplifies installation in confined spaces.
• Threaded ports (e.g., N06 = 3/4″) and NPT or Rc types make it compatible with common piping.
• Unit-selection function and accumulated flow/hysteresis settings for versatile use.
• Digital set-point adjustment and LED status indicators for switch outputs.

Technical Specifications

• Manufacturer: SMC
• Model: PFMB7202-N06-FN
• Type: Digital Flow Switch with 2-colour display
• Applicable Medium: Air, Nitrogen (quality ISO8573-1-1.1.2 to 1.6.2)
• Flow Rate Range: “7202” model typically up to approx. 2 000 L/min (for air) in standard conditions.
• Port Size: 3/4″ (N06)
• Thread Type: N (NPT) variant
• Display: 2-colour digital LCD showing actual flow, set values, alarms
• Switch Outputs: OUT1, OUT2 (switch output)
• Analogue Output: 4-20 mA
• Fluid Temperature Range: 0 °C to 50 °C (standard)
• Operating Pressure: As per series specifications (check latest catalogue)
• Display & Setting Functions: Unit selection, peak/bottom hold, accumulation, orientation correction
• Protection / Body Weight: Approx. 155 g body weight
• Installation & Piping: Straight piping section recommended per specifications to maintain accuracy
• Nature of Use: Designed for industrial pneumatic systems — not for flammable fluids or measurement-law certification use.

Applications

• Monitoring compressed air systems for flow verification and fault detection.
• Automation systems where flow thresholds must trigger control actions or alarms.
• Pneumatic distribution networks in factories – tracking consumption, identifying leaks or abnormal flows.
• Preventive maintenance programmes for air-supply systems, instrument air or nitrogen utilities.
• OEM integration into pneumatic control panels or custom systems requiring flow feedback.

Why Buy Through FieldInstruments.lk?

At FieldInstruments.lk, you benefit from:

• Authentic SMC products with full specification support.
• Competitive pricing and delivery in Sri Lanka.
• Local technical support for installation and after-sales service.
• Guidance in selecting correct variant (port size, output type, thread type) for your system.
