Kamstrup - Kamstrup MULTICAL 303 MC303-C Ultrasonic Cooling Meter, qp 1.5 m³/h, G1, 130 mm, Wired M-Bus
Kamstrup MULTICAL 303 MC303-C Ultrasonic Cooling Meter, qp 1.5 m³/h, G1, 130 mm, Wired M-Bus - MC303-C-70-5-xx-71-9-xx
| Product | Kamstrup MULTICAL 303 MC303-C Ultrasonic Cooling Meter, qp 1.5 m³/h, G1, 130 mm, Wired M-Bus |
|---|---|
| Brand | Kamstrup |
| Product Price | 0 LKR |
| Datasheet | Download |
Description
The Kamstrup MULTICAL 303 MC303-C is a complete ultrasonic cooling meter designed for reliable measurement of cooling energy consumption. The system combines an ultrasonic flow sensor, electronic calculator/display and matched Pt500 temperature sensor set in a compact design.
This configuration is supplied with a qp 1.5 m³/h flow sensor, maximum flow of 3.0 m³/h, G1 threaded connection, and 130 mm installation length. The flow sensor is suitable for PN16 and PN25 systems and incorporates a 1.5 m flow-meter cable.
The meter includes Ø5.2 mm Pt500 temperature sensors with 1.5 m cables and composite unions, together with a 35 mm sensor pocket/thermowell. Wired M-Bus and standard optical communication provide convenient integration with building management and remote meter-reading systems.
Main Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Kamstrup |
| Product Series | MULTICAL 303 |
| Type / Configuration | MC303-C-70-5-xx-71-9-xx |
| Product Type | Ultrasonic Cooling Energy Meter |
| Meter Version | Cooling Meter |
| Measurement Principle | Ultrasonic |
| Nominal Flow (qp) | 1.5 m³/h |
| Maximum Flow (qs) | 3.0 m³/h |
| Minimum Flow qi – 100:1 | 15 l/h |
| Minimum Flow qi – 250:1 | 6 l/h |
| Minimum Flow Cut-Off | 3 l/h |
| Saturation Flow | 4.6 m³/h |
| Flow Connection | G1B |
| Installation Length | 130 mm |
| Nominal Diameter | DN20 |
| Pressure Class | PN16 / PN25 |
| Pressure Loss at qp | 0.09 bar |
| Cooling Media Temperature | 2°C to 50°C |
| Flow Medium | Water |
| Temperature Sensor Type | Pt500, 2-Wire |
| Temperature Sensor Diameter | Ø5.2 mm |
| Temperature Sensor Cable | 1.5 m |
| Sensor Connection | Composite Union |
| Thermowell / Sensor Pocket | 1 × 35 mm |
| Flow Sensor Cable | 1.5 m |
| Calculator Protection | IP65 |
| Flow Sensor Protection | IP68 |
| Ambient Temperature | 5°C to 55°C |
| Communication | Wired M-Bus + Optical |
| M-Bus Speed | 300 / 2400 Baud |
| M-Bus Connection | 2-Wire, Polarity Independent |
| Display | LCD, 7 or 8 Digits |
| Energy Units | MWh / kWh / GJ |
| Data Logger | Programmable |
| Logging Interval | 1 Minute to 1 Year |
| Battery | 2 × A-Cell Lithium, 3.65 VDC |
| Battery Lifetime | Up to 16 Years |
| Wall Mounting | Wall Bracket Included |
